36 & 24 Inch Ceiling Fan Wedge Inserting Machine


36 & 24 Inch Ceiling Fan Wedge Inserting Machine

Specifications

Stator 0.D diameter 120mm to 160mm
Stack height 10mm-40mm
Number of slot 8 – 24 Poles
Motor 3 phase, 1/2 HP
Slot Indexing motor Stepper Motor
Dimension 700 x 500 x 750 mm
Net Weight 260 KG
Gross Weight 280 KG

Details

  • We manufacture and supply extremely cheap and best slot cell or wedge paper inserting machine.
  • This machine is specially designed for insulation paper of ceiling fan and motor stators.
  • All procedure actions are done by the machine automatically except to put on and take off stator.
  • The production cost will be highly reduced by decreasing the material loss and labor cost.
  • This machine is specially designed for 24” & 36″ with micro controller.


Controllers Features

  • The complete inserting time for 16 poles stator can be shortned to 6sec/ stator .
  • High insertion speed is about 0.5 sec/ slot for labor saving, cost reduction, and stable quality output.
  • Easy adjustment while changing stack height of stator or width of insulating paper.
  • Change tooling design to meet different shape of stator slots.
